RHEEM Power Inverter PD476648

PD476648 OEM replacement inverter drive for select 5-ton Rheem Prestige Series inverter outdoor units. It converts incoming 208/230V single-phase power into variable-frequency, variable-voltage output that runs the Copeland variable-speed scroll compressor.

The drive continuously modulates compressor speed to match the exact heating or cooling load instead of cycling on and off. That delivers tighter temperature and humidity control, higher seasonal efficiency (systems rated up to 20 SEER / 11 HSPF when properly matched), quieter operation at part load, and lower energy use. Built-in protections (over/under-voltage, over-current, and communication with the VSODU board) help safeguard the compressor and keep the system running reliably. Genuine OEM construction maintains factory performance, EcoNet compatibility, and warranty coverage when installed by a licensed technician.

Dimensions

Approximately:

• Length: 12.7 in
• Width / Depth: 11.55 in
• Height: 7.15 in
• Weight: ~9.18 lb

Compatibility

Direct fit for:

• RA2060AJVCB (5-ton inverter air conditioner)
• RP2060AJVCA (5-ton inverter heat pump)

Replaces: 47-105221-09 (8.0 kW class inverter)

This part is not universal. Other RA20/RP20 sizes use different kW-rated inverters (e.g., 3.7 kW or 5.5 kW versions such as PD476646 / PD476647). Always verify the exact outdoor unit model and serial number against the manufacturer parts list before ordering. Installation must be performed by a licensed HVAC technician; improper installation can damage the drive or compressor and void the warranty.

Always cross-check the unit’s service literature or call a parts specialist with the full model number to confirm fit.
